40Ft Open Side High Cube Container

Container Family is a Chinese containers factory, primarily engaged in producing various types of special containers. The 40Ft Open Side High Cube container is one of Container Family’s main products. We can manufacture 40Ft Open Side High Cube containers in various styles to meet different customers' loading and application requirements. Include 40HOS container with four side doors, 40HOS container with two side doors and 40HOS DD container with side doors etc. If you are interested in this container type, please feel free to contact us at any time.

Send Inquiry

Product Description

The 40Ft Open Side High Cube container is a specially designed maritime shipping container. It adheres to the standard length of 40 feet (approximately 12.192 meters) and features an extra-high height specification (approximately 2.896 meters), along with a side-opening door structure. Its main characteristics lie in combining an exceptionally large loading space with convenient loading and unloading functions, making it suitable for the transportation of large or extra-wide cargo.

Specification

CLASSIFICATION		DIMENSION
MAX. GROSS WEIGHT		30480 KG
TARE WEIGHT		4400 KG
MAX. PAYLOAD		26080 KG
INSIDE CUBIC CAPACITY		73.2 M3
EXTERNAL	LENGTH	12192 MM
	WIDTH	2438 MM
	HEIGHT	2896 MM
INTERNAL	LENGTH	12032 MM
	WIDTH	2292 MM
	HEIGHT	2653 MM
DOOR OPENING (REAR)	WIDTH	2340 MM
DOOR OPENING (REAR)	HEIGHT	2540 MM
DOOR OPENING (SIDE)	WIDTH	4000 MM
DOOR OPENING (SIDE)	HEIGHT	2502 MM

Feature and Application

The 40Ft High Cube Open Side Container is a versatile and robust logistics solution tailored to meet the diverse needs of numerous industries. Its defining feature is its ultra-high design, which offers significantly more space for taller or bulkier items compared to standard containers. This height advantage allows for the transportation of a wider range of goods, optimizing space utilization and reducing the need for multiple containers.

One of the most remarkable aspects of this container is its customizable side-door configuration. Available with either two or four side-opening doors, or even an optional full-side opening, the container provides unparalleled accessibility and flexibility. The side-door design enhances loading and unloading efficiency, as it allows for easy and quick access to the cargo from multiple angles. This feature facilitates the use of specialized handling equipment, reducing time and labor costs.

Wide range of applications: It is suitable for transporting oversized cargo such as large-scale mechanical equipment, automobiles, building materials, timber, and pipelines, and can also be repurposed for use in residential renovations, cafes, offices, etc.
