Duocon Container

Duocon containers(Twin-set Container) are standard-sized shipping units that can be divided into two separate modules. This feature offers unparalleled flexibility and be used in shipping、storage、disaster relief and pop-up store widely.

Send Inquiry

Product Description

Container Family is a leading special container manufacturer located in Qingdao,China. Besides the standard shipping containers,we also have the strong ability of designing and producing special containers for different applications,such as the Duocon Container.The 20foot interlinked container is a advanced style with a rotary push function,which is designed to combine two containers for different dry cargos.

We have our own factory,so we provide professional full customization service,if you have any idea,just send your inquiry,we will provide elaborate diagram and 3D drawing for you.



Duocon Container Duocon Container

Specification

20GP (2x10’ combination)
CLASSIFICATION DIMENSION
MAX. GROSS WEIGHT 30480 KG
TARE WEIGHT 2750 KG
MAX. PAYLOAD 27730 KG
INSIDE CUBIC CAPACITY 32.8 M3
EXTERNAL LENGTH 6058 MM
WIDTH 2438 MM
HEIGHT 2591 MM
INTERNAL LENGTH 5844 MM
WIDTH 2350 MM
HEIGHT 2390 MM
DOOR OPENING
(REAR)
WIDTH 2340 MM
HEIGHT 2280 MM


40HC (2x20'HC combination)
CLASSIFICATION DIMENSION
MAX. GROSS WEIGHT 32500 KG
TARE WEIGHT 4600 KG
MAX. PAYLOAD 27900 KG
INSIDE CUBIC CAPACITY 76 M3
EXTERNAL LENGTH 12192 MM
WIDTH 2438 MM
HEIGHT 2896 MM
INTERNAL LENGTH 11978 MM
WIDTH 2352 MM
HEIGHT 2698 MM
DOOR OPENING
(REAR)
WIDTH 2340 MM
HEIGHT 2586 MM

Features and Application

1. Two Door Design

The Duocon Container is separated from two containers with two doors,it is easier to access from both ends and the door can be opened easily with only one locking lever.

2. Space Saving

The special design allow the combination container accepts two different kinds of dry cargos at the same time;and if you just want to use one of the container(10’),the front wall can be swinged back,it can save your space.

3. Application

The double unit container can be divided into two separate unit,so the container is used for pop-up store、office、even home、commercial storage and disaster relief widely.

4. Full Customization Service

20GP and 40GP are normal size,we also can produce specific size for your demands.Besides,the colors(RAL)、floor material and logo can be customized,it up to you.

Duocon Container Duocon Container Duocon Container


Why Do You Need the Duocon Container and How to Get It?

From transport logistics to innovative architectural designs; from secure storage facilities to makeshift offices; from emergency disaster response centers there's no denying that Duocon shipping container uses run far and wide across various sectors highlighting their sheer versatility.

If you have the drawing,we can arrange production in short time,and if you don’t have design,just send your inquiry, we will provide professional 3D diagram for you!


FAQ

1.Do you provide on-site installation service?

We can provide installation services, detail please confirm with order management dept.

2.How can l get the quotation of the project?

lf you have drawing, we can offer quotation accordingly. lf you don't have design, we will design some drawings for your confirmation, and then offer quotation.

3.Can help to purchase the appliances and install inside?

We can help purchase some appliances if needed .Packed inside of the container and ship together.
